Leica’s CloudWorx and COE (Cyclone Object Exchange) applications allow the user to view, import, and export files between Cyclone and CAD software while maintaining links and information. Using COE Plug-In to Import & Export Objects and Points in AutoCAD Hint: You can click on any image to see a larger version.

GPS PATHFINDER OFFICE DRAWING LINES HOW TO

This workflow will show you how to use Leica’s COE plug-in to import and export objects and points in AutoCAD.
